23 High Intensity IR LEDS Color Camera w/ Sunshield
Type: Color Camera
Pick-up device: 1/3" CCD image sensor
Picture elements : EIA//NTSC: 512 H x 492 V - CCIR/PAL: 512 H x 582 V
Horizontal resolution: 420 TVL
Minimun Illumination: 0 Lux ( with IR ON)
IR Lens: 20 LEDs
Horizontal Sync.frequency: EIA//NTSC: 15.734 KHZ - CCIR/PAL: 15.625 KHZ
Vertical frequency : EIA//NTSC: 59.94 HZ - CCIR/PAL: 50 HZ
Clock frequency: EIA//NTSC: 19.0699 MHZ - CCIR/PAL: 18.9375 MHZ
Scanning system: 2:1 interlace
S/N Ratio : > 48 dB
Electronic shutter: EIA//NTSC: 1/60 ~ 1/100.000sec - CCIR/PAL: 1/50 ~
1/100.000sec
IR RAY : 880~940 nM Infrared Wave Lenght
Lens: 3.6mm
Video output: 1Vp-p , 75 Ohms
Gamma: 0.45
Power supply : DC12V (+/_10%) 0.5V
Power Consumption: 350 mA (+/_10%)
Color: Black
Housing: Aluminum
Weight: 1.5lb - 500g
Storage Temperature : -30°C ~ 60°C
Operation Temperature : -10°C ~ 45°C
|
