Specifications
|
|
Input Type |
BNC |
BNC X 4 |
|
D-Type |
DB15 X 2 |
|
Video Input(s) |
4, 8, 12, 16 Cams |
|
Audio Input(s) |
4 Channels |
|
Total Recording Rate
At 320 X 240 Resolution /
MPEG4 (ASP) |
120 fps (NTSC), 100 fps (PAL) |
|
Display Rate |
120 fps (NTSC), 100 fps (PAL).
|
|
Video Resolution
- NTSC/PAL |
Full
D1, Half D1, CIF |
|
Video Compression Format |
Geo MPEG4, Geo MPEG4 (ASP), Geo H264, Geo
H264 V2 |
|
Audio Compression Format |
ADPCM codec |
|
GV-A16 Support |
Yes |
|
GV-NET Card Support |
Yes |
|
GV-NET/IO Card Support |
Yes |
|
Dimensions (W x H) |
BNC |
152 x 101 ( mm) / 5.98 x 3.98 (in) |
|
D-Type |
174 x 107 ( mm) / 6.85 x 4.21 (in) |
|
Installation Guide |
Single Card & Two Cards |
|
Note:
GV-800 is currently not compatible with VIA series and ATI series
chipset motherboards. |
|
Minimum System Requirements
For One Card |
|
OS Supported |
32-bit |
Windows XP / Windows Vista / Windows 7 /
Windows Server 2008
|
|
64-bit |
Windows 7 / Windows Server 2008 |
|
CPU |
Pentium 4, 3.0 GHz with Hyper-threading |
|
RAM |
Windows XP: 2 x 512 MB Dual Channels
Windows Vista / 7 / Server 2008 : 2 x 1 GB Dual Channels |
|
HDD |
80 GB |
|
VGA |
ATI Radeon X600
NVIDIA 6200 |
|
DirectX |
9.0c |
|
Minimum System Requirements
For Two Cards |
|
OS Supported |
32-bit |
Windows XP / Windows Vista / Windows 7 /
Windows Server 2008
|
|
64-bit |
Windows 7 / Windows Server 2008 |
|
CPU |
Pentium 4, 3.0 GHz Dual Core |
|
RAM |
2 x 1 GB Dual Channels |
|
HDD |
160 GB |
|
VGA |
ATI Radeon X1300 PCI-E
NVIDIA GeForce 7300 PCI-E |
|
DirectX |
9.0c |
|
Não é compatível com placa mães da chipset séries VIA e séries ATI.
Recomendado Placa Mãe Chip Intel P 41 |
|
Fornecemos Placa + Micro +
Câmeras + Instalação + Configuração de Rede
|
|
 |
